| 软管尺寸 | ○ | ◎ | ○ | 额定工作压力W.P | 最小爆破压力 B.P | 最小弯曲半径 (mm) | 参考重量 (kg/m) | 内外公差 (mm) | ||||
| DN | dash | inch | I.D | R.O.D | O.D | Bar | Psi | Bar | Psi | |||
| 19 | -12 | 3/4 | 19. 0 | 28.2 | 32.0 | 420 | 6090 | 1750 | 25370 | 280 | 1.55 | |
| 25 | -16 | 1 | 25.4 | 35.1 | 38.1 | 385 | 5580 | 1750 | 25370 | 340 | 2.09 | |
| 32 | -20 | 1.1/4 | 31.8 | 42.2 | 45.2 | 350 | 5070 | 1400 | 20300 | 460 | 2.48 | |
| 38 | -24 | 1.1/2 | 38.1 | 48.7 | 53.5 | 300 | 4350 | 1250 | 18120 | 560 | 3.37 | |
| 51 | -32 | 2 | 50.8 | 63.2 | 68.0 | 250 | 3620 | 1000 | 14500 | 700 | 4.62 | |
